Carbolite TZF 1500 DegC & 1600 DegC Three Zone Tube Furnace
Maximum operating temperatures of 1500 DegC or 1600 DegC Accepts worktubes up to 90mm outside diameter Heated length of 610mm These models utilise three
sets of silicon carbide heating elements, arranged symetrically around
a separate ceramic worktube Three control systems balance the power to the heating elements to ensure excellent thermal uniformity Rapid heat up to operating temperature Can be adapted to allow a non-oxidising atmosphere or vacuum, by fitting a longer length worktube and end seals Normally built on the
horizontal base pictured left, this furnace range can optionally be
mounted vertically with a separate control box Applications in
Instrumentation include testing of temperature sensors such as
thermocouples and PT100's, that require enhanced axial thermal
uniformity Applications in materials research include testing of novel materials under strict temperature conditions Applications in the electronics industry include testing electronic components and semiconductor materials
For pricing or further information, please fill out the ENQUIRY FORM or contact us using the details below.
Please
note - Product designs and specifications are subject to change without
notice. The user is responsible for determining the suitability of this
product.
Maximum operating temperatures of 1500 DegC or 1600 DegC
