Drager PA91 Plus Advanced Breathing Apparatus


This product is now obsolete.

Ever since the company was founded in 1889, Drager has successfully risen to the challenges of an ever changing world and maintained the corporate aim of seeking and finding a solution wherever human respiration is difficult or endangered. Technology for life.

The PA91 Plus is a highly capable, yet reasonably priced, compressed air breathing apparatus set.

The PA91 Plus breathing apparatus is ideal for use when working in environments where fire and smoke, toxic gases or a lack of oxygen is present. Designed and manufactured by the world leader in the field of respiratory protective equipment, the PA91 Plus provides you with the highest level of performance in a simple but effective package.

Comfortable Carrying System

The carrying system has been orthopaedically designed and follows the contours of the back, ensuring the weight of the breathing apparatus set is concentrated on the hips and therefore reducing the risk of backstrain and fatigue.

The backplate is constructed using a strong, moulded, composite polyamide material with carbon fibre and is anti-static, chemical and impact resistant. The harness is made from flame retardant polyester webbing, with centre adjustable buckle and independent shoulder straps.

Moulded handles on the backplate provide greater manageability when transporting the set.

First Breath Activated

The Drager positive pressure Lung Demand Valve is of a balanced piston design and is first breath activated. This provides a stable air supply with low breathing resistance and is extremely quite in use. It has a wrap around silicone cover for added impact protection and is easy to service, clean and disinfect.

The Lung Demand Valve also features a centrally positioned, easily located, positive pressure 'switch off' push button.

Complete Compatibility

The carrying system incorporates an adjustable cylinder strap, which can accommodate cylinders of all sizes from 4 litres up to 12 litres in capacity. The strong polyester strap can also accommodate a twin pack cylinder arrangement as an option.

There are no special tools or procedures required for adjustment, which uses a secure, proven cam-lock mechanism.



Pneumatic Design

The high performance balanced first stage reducercan be used with 200 or 300 bar cylinders and provides excellent flow characteristics using a small, lightweight reducer body.

It incorporates a unique, patented safety pressure relief valve and allows for the easy connection of accessories. Servicing is made easier due to simple plug-in connections.

Warning Whistle & Pressure Gauge

The PA91 Plus comes complete with Drager's unique medium pressure operated warning whistle, which provides a low pressure warning in excess of 90 dBa and is consistent down to 10 bar. There is a fully luminescent gauge and the whistle warning unit assembly is fully integrated into the gauge / hose.

Accessories

The PA91 Plus can be used with any Drager full facemask and incorporates Drager's latest Plus Lung Demand Valve.

A range of accessories are available, including:

  Second LDV Connection / Female Decontamination Hose
  Decontamination Hose - Quick Release (Male)
  Twin Pack Kits
  LDV Retainer
  Chest Strap
  Cylinder Covers
  Storage Boxes


Datasheet

Drager

Please note - Product designs and specifications are subject to change without notice. The user is responsible for determining the suitability of this product.
